Examples

Built-in transmission hubs

Category: Friction welding machines
Application, field: Automobiles / vehicle parts

Bicycle parts
Material: Carbon steel

S15C×S15C
Bonding dimensions: φ43×t1.6
Conventional technique: Integrated forging
Purpose: Reduced cost

Issues to be resolved

Cutting from integrated forged parts
- High machining workload
- High material cost

Adoption merits

Cold forging is adopted by machining workpieces separately. Pressure welding by lathe turning of bonding surface only
- Machining minimization
- Reduced material cost

Applicable Model

2FW045

Differential transformers

PB x SUS304 ferromagnetic material

Clutch hubs

SPH45×S53C

Cam shafts

S45C x S45C or equivalent pipe

Constant velocity joints

S45C×S48C

Click here for list of examples

Friction welding materials

Stable, complete joints are realized, even when combining dissimilar metals or nonferrous metals.
